ICON 05-24 Ford F-450/F-550 2.5 PB Centerline Stabilizer Kit - 65054
- Catalog SKU
- ico65054
- Manufacturer part #
- 65054
- ✓Secure checkout
- ✓Enthusiast support
- ✓Free shipping on eligible $300+ merchandise subtotals in the lower 48 states
- Returns policy
Some products and vendors are excluded, including freight/LTL and oversized items.
One Parts Desk request covers fitment, availability, and timing.
Price matches are reviewed before purchase and are not guaranteed.
Project Garage
Plan this exact partSave the selected option to a build plan in this browser. No account required.
Fitment is not verified for your saved vehicle.
Product details
Product information
Overview
The ICON Centerline Steering Stabilizer features a through-shaft design to eliminate the push/pull sensation associated with traditional steering stabilizers, resulting in more consistent damping and symmetrical steering feel throughout the input range. The large 2.5-inch diameter stabilizer body and piggyback reservoir increases fluid volume to prevent performance fade due to heat and cavitation. This unit provides a significant increase in steering damping compared to the stock equipment, for an improved driving experience with both stock size and oversize aftermarket wheels and tires. The kit also allows for increased steering travel compared to other aftermarket steering stabilizers. The stabilizer body shares components with ICON's proven 2.5 Series shock absorbers, meaning the unit is fully rebuildable. 2.5 Series features a 6061 hard anodized aluminum shock body for excellent corrosion resistance and a beefy 7/8” chrome plated induction-hardened steel shaft. FK Rod End bearings provide precise function & feel throughout steering range. Installation is 100% bolt-on using common hand tools and should be an easy job for both professional mechanics and experienced DIY'ers.
APPLICATION NOTE #529: Use ICON 1” front bump stop spacers, part # 61112 (included with kit), unless the suspension system that you are using calls for larger bump stop spacers. If using a non-ICON configuration, cycle the suspension to verify that the stabilizer does not make contact upon full compression.
APPLICATION NOTE #672: Only fits 2005-2026 F-450/F-550 4WD or 2008-2010 and 2015-2016 F-350 4WD dual real wheel (DRW) equipped with Wide Track Front Axle. For standard width front axle, consider part number 65052 or 65053.
APPLICATION NOTE #528: After installation, cycle steering left and right to ensure full range of steering is achievable and stabilizer is installed correctly
APPLICATION NOTE #530: Mounts over stock front differential cover, not compatible with most aftermarket covers.
APPLICATION NOTE #531: Not compatible with aftermarket tie rods
Features & Benefits
- Through shaft design eliminates the push/pull sensation associated with traditional stabilizers
- 6061 hard anodized aluminum shock body provides excellent corrosion resistance
- 5WT shock oil for consistent suspension damping along a wide temperature range
- Offers increased wheel travel compared to ICON's dual steering stabilizer kit
- FK Rod End bearings for precise function & feel throughout steering range
- Provides symmetrical steering feel throughout input range
- Fully rebuildable ICON Vehicle Dynamics 2.5 Series shock
- Drastically increased steering damping over stock unit
- 7/8” chrome plated induction-hardened steel shaft
- Piggyback reservoir design
- 100% bolt-on installation
